Honda Rebel in new color dress

For 2022 Honda gives the CMX1100 Rebel a new color. Otherwise, not quite much changes.

[ss_click_to_tweet tweet=”Honda Rebel in new color dress – also in the MOTORCYCLES.NEWS APP” content=”Honda Rebel in new color dress – also in the MOTORCYCLES.NEWS APP” style=”default”]

For 2022 Honda gives the CMX1100 Rebel a new color. Otherwise, not quite much changes.

The CMX1100 Rebel was only released in 2021 and is the big sister of the 500cc Rebel. Purely technically, nothing has changed. In addition to the already known color bundle in black, the 2022 Rebel can also be ordered in Pearl Stallion Brown.

Known data unchanged

The 1,084 cc parallel twin from the Africa Twin continues to deliver 87 PS at 7,000 rpm and 98 Nm at 4,750 rpm in the big Rebel. The seat height is 700mm.

Never miss a story

Set MOTORCYCLES.NEWS as a preferred source on Google – our news will then appear more often in your search results.

Prefer on Google

Equipment remains Throttle by Wire with three preset riding modes, cruise control, LED lighting, LC display and USB socket under the seat. A fourth freely configurable driving mode, in which the engine brake, traction control, wheelie control and the optional dual-clutch transmission can be set in addition to the engine’s power delivery, is also available.

Technical data

MOTOR

Type – Liquid-cooled, two-cylinder SOHC four-stroke in-line engine, Unicam cylinder head, 8 valves, 270° crankshaft, Euro 5
Displacement – 1,084 cm3
Bore x stroke – 92 mm x 81.5 mm
Compression ratio – 10.1:1
Power – 64 kW (87 PS) at 7,000 rpm
Torque – 98 Nm at 4,750 rpm
Oil capacity – 4.8 liters (5.2 liters DCT)

FUEL SYSTEM

Mixture preparation – PGM-FI fuel injection system
fuel tank capacity – 13.6 liters
fuel consumption* – 4.9 liters/100km – MT – 5.3 liters/100km – DCT
CO2 emissions – 114 g/km – MT – 123 g/km – DCT

ELECTRIC

Starter – E-Starter
Battery – 12 Volt / 11,2 AH
Alternator – 419 W

DRIVE

Clutch – MT：Multi-disc in oil bath – DCT: Dual clutch transmission
Transmission – MT: 6 gears manual – DCT: 6 gears electronic-hydraulic controlled
Final drive – chain

FRAMEWORK

Type – tubular steel frame

DRIVE

Dimensions (L x W x H) – 2,240 mm x 853 mm x 1,115 mm – MT – 2,240 mm x 834 mm x 1,115 mm – DCT
Wheelbase – 1,520 mm
Steering head angle – 30
caster – 110 mm
Seat height – 700 mm
Ground clearance 120 mm
Weight full tank – MT: 223 kg / DCT: 233 kg

WHEEL HANGING

Front – 43 mm Showa cartridge partial fork, spring preload adjustable
Rear – Two Showa gas shocks with reservoir, spring preload adjustable

WHEELS

Front – Multi-spokes, cast aluminum
Rear – Multi-spokes, cast aluminum
Front rim size – MT 3.50
Rear rim size – MT 5.00
Front tire – 130/70B18 M/C
Rear tire – 180/65B16 M/C

BRAKES

ABS system – 2 channel
Front – single disc brake 330mm Ø, floating, radially mounted monobloc four-piston caliper
Rear – single disc brake 256mm Ø, single piston caliper

INSTRUMENTS & ELECTRICS
